RatiopacPRO AIR 19" Case, Retrofittable Shielding With Handles, 3/4 U, 63 HP, 315 mm

Name: RatiopacPRO AIR 19" Case, Retrofittable Shielding With Handles, 3/4 U, 63 HP, 315 mm
Brand: C-BOX
SKU: 24571-873

Flexible and robust enclosure for 19“ components or electronics assemblies and is available with advanced cooling.

Catalog#: 24571-873

Request a Quote Download Catalog (PDF)

C-BOX RatiopacPRO AIR 19" Case, Retrofittable Shielding With Handles, 3/4 U, 63 HP, 315 mm, catalog number 24571-873

Features

Aluminum construction
Passivated; Powder Coated finish
63HP rack width
3U rack height
Case
Type Case for Individual Electronic Components

Specifications

Catalog Number	24571-873
Rack Width	63HP
Rack Height	3U
Material	Aluminum
Finish	Passivated; Powder Coated
Product Type	Case
Type	Case for Individual Electronic Components
Product Family	RatiopacPRO AIR
Complies With	IEC 60297-3-101; IEC 60297-3-102; IEEE 1101.1; IEEE 1101.10; IEEE 1101.11
Static Load	25kg
Package Quantity	1
Depth	315.5mm
Usable Height	112.3mm
Usable Width	326mm
Front Frame Construction	Handles; Horizontal Rails
Cooling Option	Yes
EMC Shielding	No (Retrofittable)
Height	177mm
Protection Rating	IP20
Width	342.4mm
Net Weight	2.76kg

Item(s) Delivered

Side panel, AI, 2 mm, passivated × 2
1 Top cover and base plate, Al, 1 mm, internal surfaces conductive,visible surfaces powder-coated, RAL 9006, with GND/earthing connection, top cover and base plate with ventilation comb × 2
Case foot with anti-slip protection, UL 94 V-0, PC black × 4
Air filters × 2
Fixing materials kit × 1
Side plate, Al, 1 mm, visible surfaces powder-coated, RAL 9006 × 2
Rear trim, Al die-cast, powder-coated, RAL 7016 × 2
Horizontal rail, type H-LD, Al, visible surfaces powder coated, RAL 7016, assembled on front side bottom, for IEEE application × 1

Related Handles

Catalog#: 20808-003

Static Handle Plastic in Trapezoid Form, Grey, 5 HP

Catalog#: 20808-004

Static Handle Plastic in Trapezoid Form, Grey, 10 HP

Catalog#: 20808-060

Static Handle Plastic in Trapezoid Form, Grey, 6 HP

Catalog#: 20808-061

Static Handle Plastic in Trapezoid Form, Grey, 7 HP

Catalog#: 20808-062

Static Handle Plastic in Trapezoid Form, Grey, 8 HP

Catalog#: 20808-063

Static Handle Plastic in Trapezoid Form, Grey, 9 HP

Catalog#: 20808-064

Static Handle Plastic in Trapezoid Form, Grey, 12 HP

Catalog#: 20808-065

Static Handle Plastic in Trapezoid Form, Grey, 14 HP

Compatibility with nVent SCHROFF 24571-873

This C-BOX part is compatible with nVent SCHROFF 24571-873 — same interface dimensions, our own tooling, material and finish. It is also a direct replacement for nVent SCHROFF 24571-873: a drop-in alternative for existing 24571-873 installations, no rework required.

Cross-reference: nVent SCHROFF 24571-873, nVent 24571-873, SCHROFF 24571-873 — matching C-BOX catalog number 24571-873. Same hole pattern, same panel cut-out, same thread.

Cross-referencing a different part number? Send it to us and we will match the equivalent C-BOX part, with drawing and lead time.

Send us your drawing or part number

Need 24571-873 or a compatible custom version? Send an RFQ — engineering response within one business day.
