Plug-In Unit Kit With IEL Handle, Shielded, Black, 6 U, 10 HP

Name: Plug-In Unit Kit With IEL Handle, Shielded, Black, 6 U, 10 HP
Brand: C-BOX
SKU: 20848-597

Plug-in unit, with IET inserter/extractor black handle, 6 U, front assembly.

Catalog#: 20848-597

Request a Quote Download Catalog (PDF)

C-BOX Plug-In Unit Kit With IEL Handle, Shielded, Black, 6 U, 10 HP, catalog number 20848-597

Features

Aluminum construction
Anodized; Passivated finish
10HP rack width
6U rack height
Width 50.5mm
Height 261.8mm

Specifications

Catalog Number	20848-597
Rack Width	10HP
Rack Height	6U
Width (W)	50.5mm
Height (H)	261.8mm
Material	Aluminum
Finish	Anodized; Passivated
Product Type	Front Panel
Type	Front Panel with Handle (PIU)
Handle Type	IEL
Complies With	IEC 60297-3-102; IEEE 1101.10; IEC 60297-3-103; IEEE 1101.1/11
Package Quantity	1
Mounting	Screw-on Front; Screw-on Rear IO
Gasket Type	Textile EMC
Front Finish	Anodized
Rear Finish	Etched
Treated Edges	No
EMC Shielding	Yes
Net Weight	0.19kg

Item(s) Delivered

Front panel (U profile), AI, front anodized, rear conductive × 1
EMC sealing (textile), core: foam, sleeve: textile cladding, CuNi coated × 1
Handle with integrated alignment pin for perforated strips and guide rails, lever: plastic, PC, black, RAL 9005 Key: Plastic, PC, light grey, RAL 7035 × 1
Sleeve, PA, grey × 2
Pozidrive collar screw, M2.5 × 12.3, St, nickel-plated × 4
Panhead screw with Torx/slot, M2.5 × 6, St, zinc-plated, selflocking × 2
Washer A2.7, DIN 125, St, nickel-plated × 2
Panhead screw with Torx, M2.5 × 7, St, nickel-plated × 2
