Guide Rail, Aluminum, 160 mm, Red

Name: Guide Rail, Aluminum, 160 mm, Red
Brand: C-BOX
SKU: 24561-328
Availability: InStock

Three-piece aluminium guide rail with square load-bearing ends for 160 mm-deep PCBs in 19″ subracks.

Catalog#: 24561-328

Request a Quote Download Catalog (PDF)

C-BOX Guide Rail, Aluminum, 160 mm, Red, catalog number 24561-328

Features

Aluminium 3-piece construction
Square load-bearing end caps
Colour: Red
Board depth 160 mm
Works with Subracks; 19″ Chassis

Specifications

Catalog Number	24561-328
Complies With	IEC 60297-3-101; IEEE 1101.1; EN 60297-3-101
Material	Aluminium
Color	Red
Product Type	Guide Rail
Board Depth	160 mm
Works With	Subracks; 19″ Chassis

Related PCB Guide Rails

Catalog#: 24561-340

Guide Rail, 220 mm, Grey, for CompactPCI/VME64x

Catalog#: 24561-341

Guide Rail, 280 mm, Grey, for CompactPCI/VME64x

Catalog#: 64560-090

Guide Rail, 160 mm, Grey, Plastic

Catalog#: 64560-092

Guide Rail, 220 mm, Grey, Plastic

Catalog#: 24560-351

Guide Rail Standard Type, 160 mm, Red

Compatibility with nVent SCHROFF 24561-328

This C-BOX part is compatible with nVent SCHROFF 24561-328 — same interface dimensions, our own tooling, material and finish. It is also a direct replacement for nVent SCHROFF 24561-328: a drop-in alternative for existing 24561-328 installations, no rework required.

Cross-referencing a different part number? Send it to us and we will match the equivalent C-BOX part, with drawing and lead time.

Send us your drawing or part number

Need 24561-328 or a compatible custom version? Send an RFQ — engineering response within one business day.
