Front Panel, U-profile, Refrofit Shielding, 6 U, 28 HP, 2.5 mm, Al, Front Anodized, Rear Conductive

Name: Front Panel, U-profile, Refrofit Shielding, 6 U, 28 HP, 2.5 mm, Al, Front Anodized, Rear Conductive
Brand: C-BOX
SKU: 20848-120

U-profile front panel for textile EMC gasket.

Catalog#: 20848-120

Request a Quote Download Catalog (PDF)

Features

Aluminum construction
Anodized; Passivated finish
28HP rack width
6U rack height
Width 141.9mm
Height 261.8mm

Specifications

Catalog Number	20848-120
Rack Width	28HP
Rack Height	6U
Width (W)	141.9mm
Height (H)	261.8mm
Depth (D)	2.5mm
Material	Aluminum
Finish	Anodized; Passivated
Product Type	Front Panel
Type	Front Panel without Handle
Complies With	IEC 60297-3-101; IEEE 1101.1/10
Package Quantity	1
Accessory Type	Front panel
Mounting	Screw-on Front
Gasket Type	Textile EMC
Front Finish	Anodized
Rear Finish	Conductive
Treated Edges	No
Design Feature	Alignment pin
EMC Shielding	No (Retrofittable)
Net Weight	0.252kg
