Subrack Accessories · PCB Guide Rails

Guide Rail With Coding for CompactPCI/ VME64x, PC, 160 mm, 2 mm Groove Width, Red

With Coding type plastic guide rail for plug-in units or PCBs.

Catalog#: 64568-089

Request a Quote Download Catalog (PDF)
C-BOX Guide Rail With Coding for CompactPCI/ VME64x, PC, 160 mm, 2 mm Groove Width, Red, catalog number 64568-089

Features

  • Fiber-Reinforced Plastic construction
  • Colour: Red
  • Guide Rail
  • Type Coding
  • Works with Subracks; Cases; 19" Chassis; Systems
  • Complies with EN 45545-2

Specifications

Catalog Number64568-089
MaterialFiber-Reinforced Plastic
ColorRed
Product TypeGuide Rail
TypeCoding
Product FamilyEuropacPRO; RatiopacPRO; RatiopacPRO AIR; CompacPRO; PropacPRO; MultipacPRO; Inpac
Works WithSubracks; Cases; 19" Chassis; Systems
Complies WithEN 45545-2
Package Quantity1
Gross Weight0.008kg
Board Depth160mm
Groove Width2
